Switch OFF the BTS cabinet and disconnect Abis connectors from DDF before offline start Disconnect the Abis connector from The DDF Switch ON the BTS cabinet breakers and connect the Laptop with BTS User Name “COMMTE” Password “COMMTE” Communication Port setting OR After connecting this window will be appear Go to Configuration-> BTS-SW Download-> to download BTS software After BTSSW download this window will appear Go to offline Files and select First File of Master File. Go to offline Files and select First File of DDL file. Click ok to start downloading SW BTS software starts to download. All these Files are downloaded Go to Configuration BTS commissioning Click start commissioning Edit Qmux Address Edit sector Mapping Check All Twin TRE’s.

(2)Standard installation configuration consists of forward-facing flush-mount installation in a 19-inch equipment rack. Download gratis desain undangan pernikahan islami indonesia. (3)If installing a SAR-O or SAR-W on a wall or pole, install the bracket on the wall or pole first, then install the SAR-O or SAR-W in the bracket. (4)Applies to SAR-W variants equipped with GPS receivers only. Commissioning BTS Alcatel A9100 Offline, Online and TrubleShooting.

Click End Commissioning Click > Hardware setting>>Begin HW modification Go to configuration> BTS commissioning Go to start commissioning> Edit Q1 Address, Edit Sector Mapping and Twin TRA setting as in offline. Go to configuration> Hardware setting>“End Modification” to end online commissioning Online commissioning steps  Connect the Abis connector at DDF by verifying Tx/Rx cable properly.  OML will be established after primary Abis has      connected to DDF. Give hard reset to BTS after OML has established.

Put site on Downloading from OMC. O&M will be established as downloading completes. Connect Laptop to BTS MMI port. Go to configuration>Hardware setting>Begin Hardware modification. Online commissioning steps  Go to configuration>BTS commissioning>start        commissioning. Edit Qmux Address Edit sector mapping Check all Twin TRA setting. Click end commissioning and shift all modules from selected modules to available modules.

Go to configuration>Hardware setting>End Hardware modification. Click “yes” when an automatically hardware modification window appears. Hw Audit will be run and all Hardware will be shown after sometime. ON Line Commissioning Completed Successfully. Software components combiner Fan Unit Hardware Shown in software window Tre’s clock Alarm card Alarms window Transceivers Shown in window Transceivers Types  Four type of Transceivers in Alcatel Equipment  TRAGE>Gsm Single TRE  TRADE>Dcs single TRE  TGT09>Gsm Twin TRE  TGT18>DCS Twin TRE  TAGHE>High power TRE VSWR Shown in window Sectors Shown In window Station units BSC SBLs (security block levels) BTS OM & Sectors.Sec RSLs can be unlock from local Terminal. Troubleshooting  If a TRE or combiner is in “Not Operational” or “FOS” state then        disable it then initialize it by using “init” command. If TRE or combiner can not operational by doing above command then remove it by using the following method.

Go to configuration>>Hardware setting>>Begin HW modification. Go to Configuration>>Hardware setting>>Remove. Remove the Hardware from BTS.
